Antenna
Optimize Coverage. Maximize Performance.
Wireless performance depends on more than just the access point. Selecting the right antenna can significantly improve coverage, capacity, signal quality, and overall network reliability.
Altai offers a comprehensive portfolio of high-performance antennas designed to support a wide range of deployment requirements, from campus-wide coverage and smart city networks to industrial facilities, transportation systems, and wireless backhaul links.
Designed and tested to work seamlessly with Altai wireless solutions, our antennas help organizations build more efficient, reliable, and cost-effective wireless networks.
Choose the Right Antenna
Different deployment environments require different coverage patterns. Use the guide below to identify the antenna family best suited for your application.
Antenna Family | Best For | Coverage Pattern | Typical Applications |
Omni Antennas | Wide-area coverage in all directions | 360° Coverage | Campuses, Warehouses, Public Wi-Fi, Industrial Facilities |
Sector Antennas | Focused coverage and increased capacity | 60° / 90° / 120° Coverage | Smart Cities, Transportation, Utilities, Outdoor Networks |
Panel Antennas | Directional and long-range connectivity | Narrow Beam Coverage | Wireless Backhaul, Remote Sites, Point-to-Point Links |
Antenna Families
360° Coverage for Broad Area Connectivity
Altai Omni Antennas provide uniform wireless coverage in all directions, making them ideal for deployments where users, devices, and assets are distributed around the access point.
Designed for outdoor and industrial environments, these antennas help maximize coverage while simplifying network design.
Best For
- Campus Networks
- Public Wi-Fi
- Warehouses
- Industrial Facilities
- General Outdoor Coverage
Compare Omni Antennas
Model | Frequency | Gain | Coverage Pattern | Best For |
SD.AN-2M5F-00 | 2.4 GHz | 5 dBi | 360° | Short-Range Coverage |
SD.AN-2M8F-00 | 2.4 GHz | 8 dBi | 360° | Campus & General Outdoor Coverage |
SD.AN-2M10-00 | 2.4 GHz | 10 dBi | 360° | Large Outdoor Areas |
SD.AN-5M109-KB | 5 GHz | 9 dBi | 360° | High-Capacity Outdoor Networks |
SD.AN-5M13-00 | 5 GHz | 13 dBi | 360° | Long-Range Outdoor Deployments |
NS.AN-2M05-01 | 2.4 GHz | 5 dBi | 360° | Short-Range Indoor Coverage |
SD.AN-2M5M-HL | 2.4 GHz | 5 dBi | 360° | Short-Range Outdoor Coverage |
NS.AN-2M08-HL | 2.4 GHz | 8 dBi | 360° | Campus & General Outdoor Coverage |
NS.AN-5M09-SA | 5 GHz | 9 dBi | 360° | High-Capacity Outdoor Networks |
SD.AN-DM05-AM | Dual-Band | 5 dBi | 360° | General Purpose Coverage |
SD.AN-DM03-AM | Dual-Band | 3 dBi | 360° | Short-Range Coverage |
Focused Coverage for Higher Capacity Networks
Altai Sector Antennas deliver targeted wireless coverage for large-scale outdoor deployments where performance, capacity, and interference management are critical.
By focusing RF energy into a defined coverage area, sector antennas improve efficiency and support higher-density wireless deployments.
Best For
- Smart Cities
- Container Ports
- Transportation Networks
- Utilities
- Large Outdoor Venues
Compare Sector Antennas
Model | Frequency | Gain | Beamwidth | Best For | Compatible AP models |
NS.AN-2S08-00 | 2.4 GHz | 8 dBi | 65° | Campus & Public Wi-Fi |
|
SP.AN-2S14-01 | 2.4 GHz | 14 dBi | 70° | Smart City Networks |
|
SD.AN-2S15-00 | 5 GHz | 15 dBi | 85° | Outdoor Capacity Deployments |
|
SD.AN-5S16-00 | 5 GHz | 16 dBi | 60° | Municipal & Utility Networks |
|
SD.AN-2S15-01 | 5 GHz | 15 dBi | 100° | Long-Range Outdoor Coverage |
|
NS.AN-5S16-00 | 5 GHz | 16 dBi | 60° | High-Capacity Outdoor Networks |
|
Directional Coverage for Long-Range Connectivity
Altai Panel Antennas are designed for directional connectivity where focused coverage, higher gain, and long-distance performance are required.
These antennas are ideal for point-to-point and point-to-multipoint deployments that demand reliable and efficient wireless communication.
Best For
- Wireless Backhaul
- Remote Site Connectivity
- Industrial Networks
- Long-Distance Wireless Links
Compare Panel Antennas
Model | Frequency | Gain | Coverage Pattern | Best For | Compatible AP models |
SD.AN-5P20-00 | 5 GHz | 20 dBi | Directional | Point-to-Point Links |
|
SD.AN-5P22-KB | 5 GHz | 22 dBi | Directional | Long-Range Connectivity |
|
Need Help Selecting an Antenna?
Whether you’re extending wireless coverage across a campus, building a smart city network, or creating a long-distance wireless link, Altai can help you identify the right antenna for your deployment.
